    1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech

    Ask Lasest Price
    Brand Name : Leomed
    Model Number : Phoeonix-9C
    Certification : CE
    Price : $2000
    Payment Terms : T/T
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech

    1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech

    The Phoenix - 9C sintering furnace redefines the efficiency standard of small - sized sintering equipment. Its core advantage lies in breaking through the traditional series - connection mode of silicon - carbide rods. By precisely adjusting the voltage to drive the heating elements, this innovation not only reduces the thermal load on silicon - carbide rods, extending their service life by over 30%, but also achieves extremely fast heating. It can reach a high temperature of 1530 °C in only 20 minutes, and the entire crystallization process can be completed in as short as 40 minutes, providing an efficient solution for laboratory sample preparation and small - batch production.
    Core Product Features
    • High - Efficiency Heating System: With a heating rate of up to 200 °C/minute, it far exceeds that of similar equipment, significantly shortening the sintering cycle.
    • Precise Temperature Control: The highest temperature of 1530 °C can be stably maintained, and the longest holding time reaches 2 hours and 46 minutes, meeting the needs of complex sintering processes.
    • Flexible Power Adaptability: It is compatible with 100 - 120V and 230V voltages (50/60Hz), with currents of 14.5A@110V and 7.0A@230V respectively, suitable for power grids in most regions around the world.
    • Compact Design: The main body size is 27×36×56cm (including some accessories), the furnace core platform diameter is 6.5cm, and the net weight is only 20Kg, saving laboratory space.
    Technical Principle and Applications
    The Phoenix - 9C uses voltage - regulation technology instead of series - connection driving, making the heating of silicon - carbide rods more uniform and reducing local overheating losses. It has a wide range of applications, including ceramic material sintering, small - scale glass crystallization experiments, and metal powder densification treatment. It is especially suitable for high - frequency use in research institutions and small - scale manufacturing enterprises.
    ParameterSpecific Value
    Maximum Temperature1530 °C
    Heating RateUp to 200 °C/minute
    Power Adaptability100 - 120V/230V 50/60Hz
    Maximum Power1300W
    Furnace Core Diameter6.5cm
    Net Weight20Kg (±1Kg, subject to accessory adjustment)

    1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech

    1530°C Fast-Sintering Ceramic Furnace 200°C/Min Heating Rate Silicon Carbide Rod Tech
